JT-2000KW Yuchai Industrial Generator
2000kW Prime Power | High-Performance Energy for Mining, Oil & Gas, and Heavy Industry
- Engine: Yuchai YC16VC3300-D31 16-Cylinder V-Type Turbocharged
- Certifications: ISO9001, CE, SONCAP, PVoC, NRCS, SIRIM, SNI, TISI
- Scalability: Parallel Capability up to 8 Units (16MW Total Capacity)
Product Overview
The JT-2000KW is an industrial-grade power solution engineered for continuous baseload operation in demanding environments. Featuring the Yuchai YC16VC3300-D31 16-cylinder V-type engine, this generator delivers 2000kW of prime power with exceptional thermal stability and torque reserve. Designed for large-scale manufacturing, mining, and critical infrastructure, it offers a single-unit alternative to complex multi-generator configurations, significantly reducing installation and maintenance overhead.
Technical Specifications
| Category | Specification |
|---|---|
| Model | JT-2000KW |
| Prime Power | 2000 kW / 2500 kVA |
| Standby Power | 2200 kW / 2750 kVA |
| Voltage | 400 V |
| Rated Current | 3600 A |
| Frequency | 50 Hz |
| Engine Model | Yuchai YC16VC3300-D31, 16-Cylinder V-Type Turbocharged |
| Displacement | 105.56 L |
| Bore × Stroke | 170 mm × 230 mm |
| Compression Ratio | 14.5:1 |
| Cycle Type | 4-Cycle Diesel |
| Engine Rated Speed | 1500 RPM |
| Peak Torque @1500RPM | 13200 N·m |
| Cooling System | Water-Cooled |
| Engine Oil Capacity | 220 L |
| Start Motor Voltage | 24V DC |
| Alternator Brand & Type | Stamford/Marathon, Brushless, Self-exciting, H-Class Insulation, 3-Phase |
| Phase & Connection | 3-Phase 4-Wire |
| Power Factor | 0.8 (lagging) |
| Insulation Class | Class H |
| Protection Grade | IP21 |
| Total Harmonic Distortion (THD) | <5% |
| Fuel Consumption (100% Full Load) | 224-232 g/kW·h |
| Fuel Tank Capacity | 2600 L / ≈18-hr @ 75% Load |
| Scheduled Maintenance Interval | 500 Working Hours |
| Noise Level | 84-86 dB(A) @ 1 Meter |
| Max Operating Altitude | ≤ 1000 m |
| Max Parallel Units | Up to 8 Units (IEC 8528-5) |
| ATS Compatibility | Yes |
| Transport Dimensions | 7200 × 2600 × 3000 mm |
| Overall Weight | 17.2 t |
| Certifications | ISO9001 · CE · SONCAP · PVoC · NRCS · SIRIM · SNI · TISI |
| Lead Time | 45-50 Working Days + 40-50 Days Ocean Freight |
| Payment Term | 30% Advance, 70% Before Shipment |
Core Advantages
1. Megawatt-Scale Power Consolidation
A single 2000kW unit replaces complex multi-generator paralleling systems. This minimizes points of failure, streamlines commissioning documentation, and simplifies site-wide maintenance contracts.
2. Heavy-Duty 16-Cylinder Performance
The YC16VC3300-D31 delivers 13,200 N·m of peak torque. Its V-16 configuration provides natural primary balance, minimizing vibrational stress on alternator bearings and foundations during sustained full-load operation in mining or oil-gas fields.
3. 18-Hour Continuous Autonomy
With a 2600L integral fuel tank, this unit supports 18 hours of continuous operation at 75% load. This extended range provides critical flexibility for logistics-constrained sites like remote mining pits or off-grid port terminals.
4. Industrial-Grade Power Quality
Equipped with a Stamford/Marathon brushless alternator, the system maintains THD below 5% even under heavy inductive loading, ensuring stability for VFD-driven machinery, mining equipment, and UPS systems.
5. Modular Expansion Path (Up to 16MW)
Compliant with IEC 8528-5, these units can be paralleled up to 8 units. As your project expands—be it a mining pit deepening or a data center adding capacity—your power infrastructure scales incrementally without decommissioning original assets.
6. Centralized Fault Management
Integrated LCD diagnostics and SCADA-ready communication interfaces allow central control rooms to monitor real-time parameters and fault history, enabling predictive maintenance without the need for on-site personnel.
