JT-640KW Yuchai Industrial Generator
640kW Prime Power | Reliable Energy for Manufacturing, Mining & Infrastructure
- Engine: Genuine Yuchai YC6C1020-D31 6-Cylinder In-Line Turbocharged
- Certifications: ISO9001, CE, SONCAP, PVoC, NRCS, SIRIM, SNI, TISI
- Scalability: Parallel Capability up to 8 Units
Product Overview
The JT-640KW is a heavy-duty industrial generator engineered for 24/7 continuous operation. Powered by the authentic Yuchai YC6C1020-D31 inline 6-cylinder engine, this unit delivers 640kW of prime power with exceptional thermal stability and long-term durability. It is the ideal solution for manufacturing plants, large construction sites, and critical backup for data centers, ensuring reliable performance in demanding environments worldwide.
Technical Specifications
| Category | Specification |
|---|---|
| Model | JT-640KW |
| Prime Power | 640 kW / 800 kVA |
| Standby Power | 704 kW / 880 kVA |
| Voltage | 400/230 V |
| Rated Current | 1152 A |
| Frequency | 50 Hz |
| Engine Model | Genuine Yuchai YC6C1020-D31, 6-Cylinder In-Line Turbocharged |
| Displacement | 39.584 L |
| Bore × Stroke | 170 mm × 230 mm |
| Compression Ratio | 14.5:1 |
| Cycle Type | 4-Cycle Diesel |
| Engine Rated Speed | 1500 RPM |
| Peak Torque @1500RPM | 4600 N·m |
| Cooling System | Water-Cooled |
| Engine Oil Capacity | 92 L |
| Start Motor Voltage | 24V DC |
| Alternator Brand & Type | Stamford/Marathon, Brushless, Self-exciting, H-Class Insulation, 3-Phase |
| Phase & Connection | 3-Phase 4-Wire |
| Power Factor | 0.8 (lagging) |
| Insulation Class | Class H |
| Protection Grade | IP21 |
| Total Harmonic Distortion (THD) | <5% |
| Fuel Consumption (100% Full Load) | 216-224 g/kW·h |
| Fuel Tank Capacity | 1200 L / ≈12-hr @ 75% Load |
| Scheduled Maintenance Interval | 500 Working Hours |
| Noise Level | 78-80 dB(A) @ 1 Meter |
| Max Operating Altitude | ≤ 1000 m |
| Max Parallel Units | Up to 8 Units (IEC 8528-5) |
| ATS Compatibility | Yes |
| Transport Dimensions | 4700 × 2100 × 2500 mm |
| Overall Weight | 8.6 t |
| Certifications | ISO9001 · CE · SONCAP · PVoC · NRCS · SIRIM · SNI · TISI |
| Lead Time | 45-50 Working Days + 40-50 Days Ocean Freight |
| Payment Term | 30% Advance, 70% Before Shipment |
Core Advantages
1. Optimized 640kW Tiered Power
Perfectly calibrated for medium-large industrial loads, this unit avoids the capital waste of over-sized equipment while providing a 10% standby margin to handle sudden startup spikes.
2. 4600 N·m High-Torque Reserve
Specifically designed to handle transient loads (cranes, pumps), this high torque reserve prevents voltage drops and relay trips, maintaining process stability in complex construction environments.
3. 12-Hour Continuous Operational Autonomy
The 1200L integrated fuel tank ensures 12+ hours of runtime at 75% load, significantly reducing labor and logistics pressure for off-grid and remote mining project managers.
4. Clean Power for Automation
With THD<5%, the system delivers clean power that protects PLC systems, industrial robots, and banking/data servers from harmonic interference, preventing costly downtime and malfunctions.
5. Yuchai Heavy-Duty Reliability
Built on Yuchai’s mature inline-six platform, this generator features enhanced thermal management and reinforced structural components, proven for 24/7 reliability in extreme, high-temperature, and dusty conditions.
